A REST deploy API is just POST-then-poll with a rollback branch you hope you never need. Here’s that loop as three small, tested Ruby classes instead of a shell script nobody wants to touch.
Step through the build below:
Most “deploy” steps in CI are really: POST to some internal API, get back an id, then poll a status endpoint until it says success or failed. Wiring that up as a curl loop in a shell script works right up until you need retry logic for flaky networks, exponential backoff so you don’t hammer the API, and an automatic rollback call when the deploy fails.
This script is that loop rewritten as three small, independently testable Ruby classes: a retrying HTTP client, a poll-until-terminal state machine, and a CLI wrapper — with a real rollback branch that fires automatically on failure or timeout.
#!/usr/bin/env ruby
# frozen_string_literal: true
#
# deploy_webhook_orchestrator.rb
#
# Drives a REST-based deployment API end to end: triggers a deploy, polls
# its status until it finishes (or times out), retries transient network
# failures with exponential backoff, and automatically calls a rollback
# endpoint when the deploy fails or stalls. No gems -- net/http, json,
# uri and optparse are all in the Ruby standard library.
#
# This is the shape of almost every "deploy button" a CI system calls:
# some internal or vendor API that accepts a POST to kick off work and
# hands back an id you have to poll. Wiring that up by hand in a shell
# script (curl in a while loop) gets unreadable fast once you add retry
# logic, backoff, and a rollback branch. This script is the Ruby version
# of that shell loop, structured so each concern (HTTP client, polling,
# rollback, CLI) is a separate, testable piece.
require 'net/http'
require 'uri'
require 'json'
require 'optparse'
# --------------------------------------------------------------------------
# Raised when the HTTP client exhausts its retry budget against a single
# request. Kept distinct from other StandardErrors so the CLI can report a
# clean message instead of a raw backtrace.
# --------------------------------------------------------------------------
class RequestFailed < StandardError; end
# --------------------------------------------------------------------------
# Thin, retrying JSON HTTP client. Every call in this script -- trigger,
# poll, rollback -- goes through here, so retry/backoff logic lives in
# exactly one place.
# --------------------------------------------------------------------------
class RetryingHttpClient
# Transient failures worth retrying. A 4xx/5xx HTTP status is handled
# separately (see #request) because it isn't a Ruby exception.
RETRYABLE_ERRORS = [
Errno::ECONNREFUSED,
Errno::ECONNRESET,
Errno::ETIMEDOUT,
Net::OpenTimeout,
Net::ReadTimeout,
EOFError, # connection closed mid-response -- net/http only auto-retries this for GET, not POST
SocketError
].freeze
def initialize(base_uri, max_retries: 4, base_backoff: 0.5, logger: method(:warn))
@base_uri = base_uri
@max_retries = max_retries
@base_backoff = base_backoff
@logger = logger
end
# method: :get or :post. path: e.g. "/deploy". body: Hash (JSON-encoded) or nil.
# Returns a parsed JSON Hash on any 2xx response.
# Raises RequestFailed on a non-2xx response or after retries are exhausted.
def request(method, path, body: nil)
uri = URI.join(@base_uri.to_s, path)
attempt = 0
begin
attempt += 1
response = perform(method, uri, body)
unless response.is_a?(Net::HTTPSuccess)
raise RequestFailed, "#{method.upcase} #{path} -> HTTP #{response.code}: #{response.body}"
end
return response.body.to_s.empty? ? {} : JSON.parse(response.body)
rescue *RETRYABLE_ERRORS => e
if attempt <= @max_retries
backoff = @base_backoff * (2**(attempt - 1))
@logger.call("#{e.class}: #{e.message} (attempt #{attempt}/#{@max_retries + 1}), retrying in #{backoff}s")
sleep backoff
retry
end
raise RequestFailed, "#{method.upcase} #{path} failed after #{attempt} attempts: #{e.class}: #{e.message}"
end
end
private
def perform(method, uri, body)
http = Net::HTTP.new(uri.host, uri.port)
http.use_ssl = uri.scheme == 'https'
http.open_timeout = 5
http.read_timeout = 5
request =
case method
when :get then Net::HTTP::Get.new(uri)
when :post then Net::HTTP::Post.new(uri)
else raise ArgumentError, "unsupported method #{method}"
end
if body
request['Content-Type'] = 'application/json'
request.body = JSON.generate(body)
end
http.request(request)
end
end
# --------------------------------------------------------------------------
# Orchestrates one deploy: trigger -> poll -> (rollback on failure/timeout).
# Every collaborator (HTTP client, clock, sleeper) is injectable so tests
# never need a real network or a real timer.
# --------------------------------------------------------------------------
class DeployOrchestrator
TERMINAL_STATUSES = %w[success failed].freeze
Result = Struct.new(:outcome, :deploy_id, :status, :rolled_back, :detail, keyword_init: true)
def initialize(client:, deploy_path:, status_path_template:, rollback_path_template:,
poll_interval: 3, timeout: 300, clock: Time, sleeper: ->(s) { sleep s },
logger: method(:warn))
@client = client
@deploy_path = deploy_path
@status_path_template = status_path_template
@rollback_path_template = rollback_path_template
@poll_interval = poll_interval
@timeout = timeout
@clock = clock
@sleeper = sleeper
@logger = logger
end
# payload: Hash sent as the deploy request body (service name, version, etc).
def run(payload)
deploy_id = trigger(payload)
status = poll_until_terminal(deploy_id)
if status == 'success'
Result.new(outcome: :success, deploy_id: deploy_id, status: status, rolled_back: false)
else
# status is either "failed" or the sentinel :timeout from poll_until_terminal
rolled_back = attempt_rollback(deploy_id)
outcome = status == :timeout ? :timeout : :failed
Result.new(outcome: outcome, deploy_id: deploy_id, status: status, rolled_back: rolled_back)
end
rescue RequestFailed => e
Result.new(outcome: :error, deploy_id: nil, status: nil, rolled_back: false, detail: e.message)
end
private
def trigger(payload)
@logger.call("Triggering deploy: #{payload.inspect}")
response = @client.request(:post, @deploy_path, body: payload)
id = response['id'] || response['deploy_id']
raise RequestFailed, "deploy trigger response had no id/deploy_id field: #{response.inspect}" unless id
@logger.call("Deploy accepted, id=#{id}")
id
end
def poll_until_terminal(deploy_id)
deadline = @clock.now + @timeout
path = @status_path_template % { id: deploy_id }
loop do
response = @client.request(:get, path)
status = response['status']
@logger.call("Status for #{deploy_id}: #{status}")
return status if TERMINAL_STATUSES.include?(status)
if @clock.now >= deadline
@logger.call("Timed out after #{@timeout}s waiting for #{deploy_id} to finish (last status: #{status})")
return :timeout
end
@sleeper.call(@poll_interval)
end
end
def attempt_rollback(deploy_id)
path = @rollback_path_template % { id: deploy_id }
@logger.call("Rolling back #{deploy_id}...")
@client.request(:post, path)
@logger.call("Rollback request for #{deploy_id} accepted")
true
rescue RequestFailed => e
@logger.call("Rollback for #{deploy_id} FAILED: #{e.message}")
false
end
end
# --------------------------------------------------------------------------
# CLI
# --------------------------------------------------------------------------
if __FILE__ == $PROGRAM_NAME
options = {
status_path_template: '/status/%<id>s',
rollback_path_template: '/rollback/%<id>s',
deploy_path: '/deploy',
poll_interval: 3,
timeout: 300,
max_retries: 4,
payload: {}
}
parser = OptionParser.new do |opts|
opts.banner = 'Usage: deploy_webhook_orchestrator.rb --base-url URL [options]'
opts.on('--base-url URL', 'Base URL of the deploy API (required)') { |v| options[:base_url] = v }
opts.on('--deploy-path PATH', "Path to POST to trigger a deploy (default #{options[:deploy_path]})") { |v| options[:deploy_path] = v }
opts.on('--status-path-template TPL', "printf-style path with %<id>s (default #{options[:status_path_template]})") { |v| options[:status_path_template] = v }
opts.on('--rollback-path-template TPL', "printf-style path with %<id>s (default #{options[:rollback_path_template]})") { |v| options[:rollback_path_template] = v }
opts.on('--payload JSON', 'JSON body to send with the deploy trigger, e.g. {"service":"api","version":"1.4.2"}') { |v| options[:payload] = JSON.parse(v) }
opts.on('--poll-interval SECONDS', Float, "Seconds between status polls (default #{options[:poll_interval]})") { |v| options[:poll_interval] = v }
opts.on('--timeout SECONDS', Float, "Give up and roll back after this many seconds (default #{options[:timeout]})") { |v| options[:timeout] = v }
opts.on('--max-retries N', Integer, "Retries per HTTP call on transient network errors (default #{options[:max_retries]})") { |v| options[:max_retries] = v }
opts.on('-h', '--help', 'Show this help') { puts opts; exit 0 }
end
parser.parse!(ARGV)
unless options[:base_url]
warn parser
exit 4
end
client = RetryingHttpClient.new(options[:base_url], max_retries: options[:max_retries])
orchestrator = DeployOrchestrator.new(
client: client,
deploy_path: options[:deploy_path],
status_path_template: options[:status_path_template],
rollback_path_template: options[:rollback_path_template],
poll_interval: options[:poll_interval],
timeout: options[:timeout]
)
result = orchestrator.run(options[:payload])
case result.outcome
when :success
puts "DEPLOY SUCCESS id=#{result.deploy_id}"
exit 0
when :failed
puts "DEPLOY FAILED id=#{result.deploy_id} rolled_back=#{result.rolled_back}"
exit(result.rolled_back ? 1 : 3)
when :timeout
puts "DEPLOY TIMEOUT id=#{result.deploy_id} rolled_back=#{result.rolled_back}"
exit(result.rolled_back ? 2 : 3)
when :error
puts "ORCHESTRATION ERROR: #{result.detail}"
exit 5
end
end
RetryingHttpClient is the one place every HTTP call goes through. It retries ECONNREFUSED, ECONNRESET, timeouts, and a dropped-mid-response EOFError with exponential backoff (base_backoff * 2**(attempt-1)). A non-2xx HTTP status raises immediately — that’s not transient, retrying a real 500 won’t fix it.
DeployOrchestrator#run is the actual state machine: trigger → poll in a loop until status is success/failed or the deadline passes → branch to a clean exit or attempt_rollback. The clock and sleeper are constructor arguments, so tests never actually wait out a real timeout.
One non-obvious thing the test suite had to work around: Ruby’s net/http silently retries a GET once on its own if the connection resets before any bytes come back — it does not do this for POST, since POST isn’t assumed idempotent. That’s why the transient-failure test drops the connection on the deploy-triggering POST rather than a status GET: dropping the GET would have been absorbed by net/http itself before this script’s own retry logic ever saw it.
=== Test suite (deploy_webhook_orchestrator_test.rb) ===
Scenario 1: successful deploy
ok - outcome is :success (got success)
ok - deploy_id captured from trigger response
ok - polled 3 times before success (got 3)
Scenario 2: failed deploy triggers rollback
ok - outcome is :failed (got failed)
ok - rollback was performed
ok - rollback endpoint was actually hit
Scenario 3: transient connection drop on trigger is retried transparently
ok - outcome recovers to :success (got success)
ok - server saw exactly 2 attempts for the dropped trigger POST (got 2)
ok - client logged a retry for the dropped connection
All scenarios passed.
=== CLI run: deploy succeeds ===
$ ruby deploy_webhook_orchestrator.rb --base-url http://127.0.0.1:36035 \
--payload '{"service":"billing-api","version":"1.4.2"}' --poll-interval 1 --timeout 30
DEPLOY SUCCESS id=dep-4821
exit status: 0
=== CLI run: deploy fails, rollback fires ===
$ ruby deploy_webhook_orchestrator.rb --base-url http://127.0.0.1:45113 \
--payload '{"service":"billing-api","version":"1.5.0-rc1"}' --poll-interval 1 --timeout 30
DEPLOY FAILED id=dep-4821 rolled_back=true
exit status: 1
Get the code
Full script + README on GitHub: ruby-devops-toolkit/deploy-webhook-orchestrator
Prerequisites
What you need
Prerequisites
- Ruby >= 3.0 (developed and tested on 3.3.6)
- No gems —
net/http,json,uri, andoptparseare all standard library - Linux, macOS, or Windows — plain
net/http, no OS-specific calls - A deploy API that accepts a POST to trigger a deploy and returns an id, exposes a status GET, and a rollback POST
Walkthrough
How it works, end to end
The script is three collaborators, wired together in the CLI block at the bottom of the file:
- RetryingHttpClient wraps every GET/POST in retry + exponential-backoff logic, configurable via
--max-retries. - DeployOrchestrator holds the actual state machine:
trigger→poll_until_terminal→ success, orattempt_rollbackon failure/timeout. - The CLI block parses
ARGV, builds both objects, runs the orchestrator, and maps itsResult#outcometo a process exit code —0success,1failed+rolled back,2timeout+rolled back,3rollback itself also failed,5the trigger request never got through at all.
Every collaborator takes its dependencies as constructor arguments (the HTTP client, the clock, the sleeper) — that’s what let the test suite exercise real timeout and retry behavior in milliseconds against a local stub server instead of actually sleeping through a 300-second deadline.
trigger → poll → rollback, and where each class sits in that flow
Full code
deploy_webhook_orchestrator.rb
#!/usr/bin/env ruby
# frozen_string_literal: true
#
# deploy_webhook_orchestrator.rb
#
# Drives a REST-based deployment API end to end: triggers a deploy, polls
# its status until it finishes (or times out), retries transient network
# failures with exponential backoff, and automatically calls a rollback
# endpoint when the deploy fails or stalls. No gems -- net/http, json,
# uri and optparse are all in the Ruby standard library.
#
# This is the shape of almost every "deploy button" a CI system calls:
# some internal or vendor API that accepts a POST to kick off work and
# hands back an id you have to poll. Wiring that up by hand in a shell
# script (curl in a while loop) gets unreadable fast once you add retry
# logic, backoff, and a rollback branch. This script is the Ruby version
# of that shell loop, structured so each concern (HTTP client, polling,
# rollback, CLI) is a separate, testable piece.
require 'net/http'
require 'uri'
require 'json'
require 'optparse'
# --------------------------------------------------------------------------
# Raised when the HTTP client exhausts its retry budget against a single
# request. Kept distinct from other StandardErrors so the CLI can report a
# clean message instead of a raw backtrace.
# --------------------------------------------------------------------------
class RequestFailed < StandardError; end
# --------------------------------------------------------------------------
# Thin, retrying JSON HTTP client. Every call in this script -- trigger,
# poll, rollback -- goes through here, so retry/backoff logic lives in
# exactly one place.
# --------------------------------------------------------------------------
class RetryingHttpClient
# Transient failures worth retrying. A 4xx/5xx HTTP status is handled
# separately (see #request) because it isn't a Ruby exception.
RETRYABLE_ERRORS = [
Errno::ECONNREFUSED,
Errno::ECONNRESET,
Errno::ETIMEDOUT,
Net::OpenTimeout,
Net::ReadTimeout,
EOFError, # connection closed mid-response -- net/http only auto-retries this for GET, not POST
SocketError
].freeze
def initialize(base_uri, max_retries: 4, base_backoff: 0.5, logger: method(:warn))
@base_uri = base_uri
@max_retries = max_retries
@base_backoff = base_backoff
@logger = logger
end
# method: :get or :post. path: e.g. "/deploy". body: Hash (JSON-encoded) or nil.
# Returns a parsed JSON Hash on any 2xx response.
# Raises RequestFailed on a non-2xx response or after retries are exhausted.
def request(method, path, body: nil)
uri = URI.join(@base_uri.to_s, path)
attempt = 0
begin
attempt += 1
response = perform(method, uri, body)
unless response.is_a?(Net::HTTPSuccess)
raise RequestFailed, "#{method.upcase} #{path} -> HTTP #{response.code}: #{response.body}"
end
return response.body.to_s.empty? ? {} : JSON.parse(response.body)
rescue *RETRYABLE_ERRORS => e
if attempt <= @max_retries
backoff = @base_backoff * (2**(attempt - 1))
@logger.call("#{e.class}: #{e.message} (attempt #{attempt}/#{@max_retries + 1}), retrying in #{backoff}s")
sleep backoff
retry
end
raise RequestFailed, "#{method.upcase} #{path} failed after #{attempt} attempts: #{e.class}: #{e.message}"
end
end
private
def perform(method, uri, body)
http = Net::HTTP.new(uri.host, uri.port)
http.use_ssl = uri.scheme == 'https'
http.open_timeout = 5
http.read_timeout = 5
request =
case method
when :get then Net::HTTP::Get.new(uri)
when :post then Net::HTTP::Post.new(uri)
else raise ArgumentError, "unsupported method #{method}"
end
if body
request['Content-Type'] = 'application/json'
request.body = JSON.generate(body)
end
http.request(request)
end
end
# --------------------------------------------------------------------------
# Orchestrates one deploy: trigger -> poll -> (rollback on failure/timeout).
# Every collaborator (HTTP client, clock, sleeper) is injectable so tests
# never need a real network or a real timer.
# --------------------------------------------------------------------------
class DeployOrchestrator
TERMINAL_STATUSES = %w[success failed].freeze
Result = Struct.new(:outcome, :deploy_id, :status, :rolled_back, :detail, keyword_init: true)
def initialize(client:, deploy_path:, status_path_template:, rollback_path_template:,
poll_interval: 3, timeout: 300, clock: Time, sleeper: ->(s) { sleep s },
logger: method(:warn))
@client = client
@deploy_path = deploy_path
@status_path_template = status_path_template
@rollback_path_template = rollback_path_template
@poll_interval = poll_interval
@timeout = timeout
@clock = clock
@sleeper = sleeper
@logger = logger
end
# payload: Hash sent as the deploy request body (service name, version, etc).
def run(payload)
deploy_id = trigger(payload)
status = poll_until_terminal(deploy_id)
if status == 'success'
Result.new(outcome: :success, deploy_id: deploy_id, status: status, rolled_back: false)
else
# status is either "failed" or the sentinel :timeout from poll_until_terminal
rolled_back = attempt_rollback(deploy_id)
outcome = status == :timeout ? :timeout : :failed
Result.new(outcome: outcome, deploy_id: deploy_id, status: status, rolled_back: rolled_back)
end
rescue RequestFailed => e
Result.new(outcome: :error, deploy_id: nil, status: nil, rolled_back: false, detail: e.message)
end
private
def trigger(payload)
@logger.call("Triggering deploy: #{payload.inspect}")
response = @client.request(:post, @deploy_path, body: payload)
id = response['id'] || response['deploy_id']
raise RequestFailed, "deploy trigger response had no id/deploy_id field: #{response.inspect}" unless id
@logger.call("Deploy accepted, id=#{id}")
id
end
def poll_until_terminal(deploy_id)
deadline = @clock.now + @timeout
path = @status_path_template % { id: deploy_id }
loop do
response = @client.request(:get, path)
status = response['status']
@logger.call("Status for #{deploy_id}: #{status}")
return status if TERMINAL_STATUSES.include?(status)
if @clock.now >= deadline
@logger.call("Timed out after #{@timeout}s waiting for #{deploy_id} to finish (last status: #{status})")
return :timeout
end
@sleeper.call(@poll_interval)
end
end
def attempt_rollback(deploy_id)
path = @rollback_path_template % { id: deploy_id }
@logger.call("Rolling back #{deploy_id}...")
@client.request(:post, path)
@logger.call("Rollback request for #{deploy_id} accepted")
true
rescue RequestFailed => e
@logger.call("Rollback for #{deploy_id} FAILED: #{e.message}")
false
end
end
# --------------------------------------------------------------------------
# CLI
# --------------------------------------------------------------------------
if __FILE__ == $PROGRAM_NAME
options = {
status_path_template: '/status/%<id>s',
rollback_path_template: '/rollback/%<id>s',
deploy_path: '/deploy',
poll_interval: 3,
timeout: 300,
max_retries: 4,
payload: {}
}
parser = OptionParser.new do |opts|
opts.banner = 'Usage: deploy_webhook_orchestrator.rb --base-url URL [options]'
opts.on('--base-url URL', 'Base URL of the deploy API (required)') { |v| options[:base_url] = v }
opts.on('--deploy-path PATH', "Path to POST to trigger a deploy (default #{options[:deploy_path]})") { |v| options[:deploy_path] = v }
opts.on('--status-path-template TPL', "printf-style path with %<id>s (default #{options[:status_path_template]})") { |v| options[:status_path_template] = v }
opts.on('--rollback-path-template TPL', "printf-style path with %<id>s (default #{options[:rollback_path_template]})") { |v| options[:rollback_path_template] = v }
opts.on('--payload JSON', 'JSON body to send with the deploy trigger, e.g. {"service":"api","version":"1.4.2"}') { |v| options[:payload] = JSON.parse(v) }
opts.on('--poll-interval SECONDS', Float, "Seconds between status polls (default #{options[:poll_interval]})") { |v| options[:poll_interval] = v }
opts.on('--timeout SECONDS', Float, "Give up and roll back after this many seconds (default #{options[:timeout]})") { |v| options[:timeout] = v }
opts.on('--max-retries N', Integer, "Retries per HTTP call on transient network errors (default #{options[:max_retries]})") { |v| options[:max_retries] = v }
opts.on('-h', '--help', 'Show this help') { puts opts; exit 0 }
end
parser.parse!(ARGV)
unless options[:base_url]
warn parser
exit 4
end
client = RetryingHttpClient.new(options[:base_url], max_retries: options[:max_retries])
orchestrator = DeployOrchestrator.new(
client: client,
deploy_path: options[:deploy_path],
status_path_template: options[:status_path_template],
rollback_path_template: options[:rollback_path_template],
poll_interval: options[:poll_interval],
timeout: options[:timeout]
)
result = orchestrator.run(options[:payload])
case result.outcome
when :success
puts "DEPLOY SUCCESS id=#{result.deploy_id}"
exit 0
when :failed
puts "DEPLOY FAILED id=#{result.deploy_id} rolled_back=#{result.rolled_back}"
exit(result.rolled_back ? 1 : 3)
when :timeout
puts "DEPLOY TIMEOUT id=#{result.deploy_id} rolled_back=#{result.rolled_back}"
exit(result.rolled_back ? 2 : 3)
when :error
puts "ORCHESTRATION ERROR: #{result.detail}"
exit 5
end
end
Testing
How this was verified
Test coverage
- A hand-rolled HTTP stub server built directly on
TCPServer(no webrick, no gems, so the whole repo stays installable with a stock Ruby) plays the deploy API’s part. - Scenario 1 — happy path: two
runningpolls thensuccess. - Scenario 2 — deploy goes
failed, rollback endpoint gets hit and succeeds. - Scenario 3 — the trigger POST drops mid-connection on the first attempt; the retrying client recovers with zero visible error to the orchestrator.
- All three run live in a Linux sandbox in well under a second — see the output tab above for the actual captured run, plus two real CLI invocations against the same stub server (success and failure/rollback paths).
Troubleshooting
Common issues
Troubleshooting
- ORCHESTRATION ERROR after N attempts — the deploy API never became reachable within
--max-retries. Check--base-urlfirst. - Deploy times out even though it eventually succeeds — raise
--timeout, or lower--poll-intervalfor a faster true signal without moving the deadline. - Rollback also fails (exit 3) — the deploy is in a bad state and the API won’t take the rollback call. Treat this as a page, not a log line.
- A JSON
--payloadgets mangled by your shell — put it in a file and use--payload "$(cat payload.json)"instead of inlining quotes.
Extending it
Where to take this next
Ideas
- A
--config FILE(YAML) so payloads, path templates, and timeouts don’t all have to live on one command line across a dozen different CI jobs. - Bearer-token or HMAC-signed auth headers —
RetryingHttpClient#performis the one place to add it. - A
--webhook-notify URLso the rollback branch actually pages someone instead of exiting 1 in a CI log nobody reads until morning.
